Kelford KVS63-BTK-X Premium Nitride Beehive Valve Springs & Titanium Retainers - Mitsubishi Lancer Evolution I-IX / 4G63 MIVEC

Item: Premium Nitride Beehive Valve Spring & Titanium Retainer Kit
SKU: KVS63-BTK-X
Brand: Kelford Cams
Engine Compatibility: Mitsubishi 4G63T DOHC 16V Turbo (All generations including MIVEC)
Vehicle Fitment: Lancer Evolution I / II / III / IV / V / VI / VII / VIII / IX (Evo 1-9), Galant VR-4, Eclipse DSM (1G / 2G)
Spring Material: Premium High-Performance PACALOY Clean Spring Steel
Surface Treatment: Advanced Nitride Case Hardened Finish (Exclusive to BTK-X)
Spring Style: Beehive (Conical Valve Spring Design)
Retainer Material: Ultra-Lightweight Aerospace-Grade Titanium
Recommended Installation Seat Pressure: 90lb Seat Pressure
Maximum Allowable Valve Lift: 13.50mm
Target Application: High RPM, High Boost Competition Engines (Time Attack, Drag, Circuit Racing)
Kit Contents: 16x Nitride-Treated Beehive Springs, 16x Ultra-Lightweight Titanium Retainers, 16x Hardened Seat Locators
MIVEC Compatibility Note: Fully compatible with the Evolution 9 MIVEC cylinder head configuration. Highly recommended for builds pairing extreme boost with Kelford 9-TX series high-lift camshafts.

Kelford KVS63-BTK-X Premium Nitride Beehive Valve Springs & Titanium Retainers - Mitsubishi Lancer Evolution I-IX / 4G63 MIVEC

RM2,850.00 MYR
Enquire on WhatsApp
Eliminate high-boost valve float completely under extreme track conditions by deploying these premium nitrated PACALOY blend beehive springs. Engineered purposefully to survive alongside aggressive high-lift motorsport camshaft profiles like the Kelford 8-TX and 9-TX racing lines, this system delivers the critical valvetrain control required for massive boost loads. They represent the definitive engine hardware insurance policy for high-frequency competition platforms running extreme turbo pressures.
Maximize component fatigue resistance drastically thanks to a specialized chemical nitride surface hardening treatment applied to the spring wire. This advanced architectural treatment alters the metal substrate to minimize surface friction, prevent thermal degradation, and completely shield your assembly from destructive harmonics at high operating limits. Paired with the included ultra-lightweight titanium retainers, it strips significant weight from your top-end assembly to drastically optimize engine responsiveness.
Deploy a seamless professional valvetrain overhaul engineered directly for a drop-in physical fit across both traditional and variable MIVEC 16-valve cylinder head architectures. Because it ships as a complete top-tier racing package, you can discard weak factory hardware configurations in favor of comprehensive motorsport-grade components. This kit acts as a vital structural requirement for competitive time attack, professional drift, and drag vehicles operating across high RPM powerbands.
